A compact domestic sewage treatment plant: ECOTED delivers treated effluent fit for reuse and/or discharge with maximum safety.
Approved
hover and move the mouse · scroll to zoom
A compact domestic sewage treatment plant, ECOTED delivers treated effluent fit for reuse and/or discharge with maximum safety.
Aerobic treatment that removes over 90% of the sewage's organic load, measured as BOD and COD.
The treated water comes back fit for reuse and cuts the building's potable water consumption by up to 70%.
Designed to withstand soil loads, it can be buried in the garden without any civil works, fully plug'n play. Above-ground versions are also available.
Sized by our specialists, installation is quick and practical, leaving the system ready the moment it is put in place.
A compact plant designed for environmental and legal compliance, for projects with demanding standards.
A decentralized, single-family sanitation solution for homes that want cutting-edge sewage treatment technology — or even plan to reuse their treated sewage.
Buried or above ground, ECOTED can be installed in corporate facilities, ensuring a high-performance, odor-free system with low OPEX — saving water through reuse.
ECOTED can be applied in collective settings, sized according to the existing population, becoming a definitive, odor-free solution with low OPEX and a high guarantee of quality in sewage treatment — and even reuse.
From sewage leaving the house to treated effluent — step by step in the compact plant buried in the garden.
Click each number on the drawing to see the stage — from preparing the trench to backfilling. The exact dimensions of each model are in the product manual.
Dig/excavate the trench to the dimensions given in the product manual.
Prepare the bedding with 20 cm of No. 1 crushed stone and 20 cm of coarse sand, forming a firm, level base.
Place the tank in the trench and anchor it if necessary, ensuring the inlets and outlets are aligned.
Add sand up to half the tank's height, surrounding it evenly.
Fill 50% of the tank's volume with water to balance pressures during backfilling.
Connect the system's inlet and outlet piping according to the hydraulic design.
Connect the power supply for the air blower — it keeps the aerobic stage of treatment running.
Complete the final backfill and landscaping — the system stays buried and invisible in the garden.
